Maryland Precision Spring

SSP-321335-N - 0.512 Inch ID 1.26 Inch OD 17-7 PH Stainless Steel Disc Spring Washer

Disc spring manufactured from 17-7 PH Stainless Steel with an inside diameter of 0.512 Inch and an outside diameter of 1.26 Inch.

Unit System
Specs (in standard)
Label Value
Bolt Size 0.5
Brand Maryland Precision Spring
Display Name SSP-321335-N
Finish Nickel
Inside Diameter 0.512 in
Linear Density 40.5 lb/m
Load at Flat 9900 lb
Material 17-7 PH Stainless Steel
Outside Diameter 1.26 in
Outside Height 0.169 in
Outside Height 2 0.031 in
SKU SSP-321335-N
Screw Size M12
T 0.138 in
Specs (in metric)
Label Value
Bolt Size 0.5
Brand Maryland Precision Spring
Display Name SSP-321335-N
Finish Nickel
Inside Diameter 13 mm
Linear Density 89.29 kg/m
Load at Flat 4489.8 kg
Material 17-7 PH Stainless Steel
Outside Diameter 32 mm
Outside Height 4.29 mm
Outside Height 2 0.79 mm
SKU SSP-321335-N
Screw Size M12
T 3.51 mm
