Maryland Precision Spring

SAI-753828-301-N - 0.382 Inch ID 0.75 Inch OD 301 Stainless Steel Disc Spring Washer

Disc spring manufactured from 301 Stainless Steel with an inside diameter of 0.382 Inch and an outside diameter of 0.75 Inch.

Unit System
Specs (in standard)
Label Value
Bolt Size 0.375
Brand Maryland Precision Spring
Display Name SAI-753828-301-N
Finish Nickel
H 0.023 in
Inside Diameter 0.382 in
Material 301 Stainless Steel
Maximum Deflection at 100% Height 0.023 in
Maximum Force at 100% Height 183 lb
Outside Diameter 0.75 in
Outside Height 0.051 in
SKU SAI-753828-301-N
T 0.028 in
Specs (in metric)
Label Value
Bolt Size 0.38
Brand Maryland Precision Spring
Display Name SAI-753828-301-N
Finish Nickel
H 0.58 mm
Inside Diameter 9.7 mm
Material 301 Stainless Steel
Maximum Deflection at 100% Height 0.58 mm
Maximum Force at 100% Height 82.99 kg
Outside Diameter 19.05 mm
Outside Height 1.3 mm
SKU SAI-753828-301-N
T 0.71 mm
