Century Spring

CF200CS - 0.5 Inch x 25 Inch Constant Force Spring

Inventory Status
Estimated Lead Time

2 Pound constant force spring - 0.5 Inch by 25 Inch with a hole diameter of 0.19 Inch.

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name CF200
Drum Diameter 0.504 in
Finish None
Hole Diameter 0.19 in
Inside Diameter 0.463 in
Length 25 in
Load 2 lb
Material Spring Steel
Measurement Units Standard
Number of Holes 1
SKU CF200CS
Thickness 0.006 in
Width 0.5 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name CF200
Drum Diameter 12.8 mm
Finish None
Hole Diameter 4.83 mm
Inside Diameter 11.76 mm
Length 635 mm
Load 0.91 kg
Material Spring Steel
Measurement Units Standard
Number of Holes 1
SKU CF200CS
Thickness 0.15 mm
Width 12.7 mm
