Maryland Precision Spring

AK-6014 - 2.972 Inch ID 4.291 Inch OD 1075 Steel Disc Spring Washer

Disc spring manufactured from 1075 Steel with an inside diameter of 2.972 Inch and an outside diameter of 4.291 Inch.

Unit System
Specs (in standard)
Label Value
Ball Bearing Size 6014, 6212
Brand Maryland Precision Spring
Deflection at 75% Height 0.043 in
Display Name AK-6014
Finish Phosphate
Inside Diameter 2.972 in
Load at 75% Height 91.1 lb
Material 1075 Steel
Measurement Units Standard
Outside Diameter 4.291 in
Outside Height 0.106 in
SKU AK-6014
T 0.049 in
Specs (in metric)
Label Value
Ball Bearing Size 6014, 6212
Brand Maryland Precision Spring
Deflection at 75% Height 1.09 mm
Display Name AK-6014
Finish Phosphate
Inside Diameter 75.49 mm
Load at 75% Height 41.32 kg
Material 1075 Steel
Measurement Units Standard
Outside Diameter 108.99 mm
Outside Height 2.69 mm
SKU AK-6014
T 1.24 mm
