Century Spring

50565SCS - 3.346" 316 Stainless Steel Compression Spring

Inventory Status
Estimated Lead Time

Compression spring manufactured from 316 stainless steel with 16.8 coils and closed & ground ends. This spring features an O.D. of 0.722", and an I.D. of 0.482".

Download CAD
Unit System
Specs (in standard)
Label Value
Brand Century Spring
Display Name 50565S
Ends Closed & Ground
Finish Passivated
Free Length 3.346 in
Inside Diameter 0.482 in
Material 316 Stainless Steel
Outside Diameter 0.722 in
Rate 80.342 lbs/in
SKU 50565SCS
Solid Length 2.017 in
Suggested Max Deflection 0.733 in
Suggested Max Load 58.86 lbf
Total Coils 16.8
Wire Diameter 0.12 in
Specs (in metric)
Label Value
Brand Century Spring
Display Name 50565S
Ends Closed & Ground
Finish Passivated
Free Length 84.99 mm
Inside Diameter 12.24 mm
Material 316 Stainless Steel
Outside Diameter 18.34 mm
Rate 14.07 N/mm
SKU 50565SCS
Solid Length 51.23 mm
Suggested Max Deflection 18.62 mm
Suggested Max Load 261.81 N
Total Coils 16.8
Wire Diameter 3.05 mm
The 50565S compression spring is engineered for optimal performance in demanding applications. Constructed from high-quality 316 stainless steel and designed with precision and durability in mind, this spring is an essential component for a variety of mechanical systems where reliable force and resilience are paramount.

The 50565SCS compression spring is designed with a free length of 3.15" total of 17.3 coils, and a rate of 77.716 lbs/in providing a balanced combination of flexibility and strength. This spring coil, and its closed & ground end configuration allows for efficient energy storage and release, making it suitable for applications requiring precise motion control.

The 50565S spring design is ideal for use in industrial machinery, automotive systems, and various mechanical assemblies where reliable force application is crucial. Its robust construction and thoughtful design make it a dependable choice for engineers seeking a high-performance spring solution.
